Linear Actuators - Stepper

Tin-Can or Permanent Magnet Linear Stepper Actuators

Tin-Can Linear Stepper Actuators are a type of linear actuator that provides precise and accurate linear motion using a sequence of alternating magnetic fields. McLennan Servo Supplies offers a range of Tin-Can Linear Stepper Actuators, including lead screw and captive options, suitable for various industrial and automation applications.

Technical Description:

Tin-Can Linear Stepper Actuators consist of a series of permanent magnets arranged in a cylindrical shape, surrounded by a set of electromagnetic coils. The magnetic fields are sequentially energized to create a force on the actuator, causing it to move linearly. Lead screw Tin-Can Linear Stepper Actuators have a threaded shaft that rotates to provide linear motion, while captive Tin-Can Linear Stepper Actuators have a non-rotating shaft that moves axially.

Applications:

Tin-Can Linear Stepper Actuators are used in a variety of industrial and automation applications. Some common applications include:

  • Robotics
  • Medical equipment
  • Packaging and labeling equipment
  • Aerospace and defense
  • Material handling systems
  • Factory automation
  • Automotive systems
  • Textile machinery

Frequently Asked Questions:

Q: What are the advantages of using Tin-Can Linear Stepper Actuators? A: Tin-Can Linear Stepper Actuators offer high precision and repeatability, low maintenance, and are ideal for applications that require precise linear motion control.

Q: What load capacities do Tin-Can Linear Stepper Actuators offer? A: McLennan Servo Supplies offers Tin-Can Linear Stepper Actuators with load capacities ranging from a few grams to several kilograms.

Q: Can Tin-Can Linear Stepper Actuators be used in harsh environments? A: Yes, McLennan Servo Supplies offers Tin-Can Linear Stepper Actuators with IP65 and IP67 ratings, making them suitable for use in harsh environments.

Q: How are Tin-Can Linear Stepper Actuators controlled? A: Tin-Can Linear Stepper Actuators are typically controlled using a motion controller or a programmable logic controller (PLC) that sends commands to an amplifier that drives the electromagnetic coils. McLennan Servo Supplies offers a range of motion controllers and amplifiers suitable for use with Tin-Can Linear Stepper Actuators.

Mclennan stock & supply a huge variety of Hybrid and permanent magnet linear steppers. The sizes range from Nema14 mm up to large Nema34 high torque units. These can be supplied with connectors, wiring harness and drives to suit your application.

If you are interested or would like any advice/help in choosing the right stepper motor for your application, please pick up the phone or email us and we will be happy to help!



20DBM-K High Power Stepper Linear Actuator

The 20DBM-K high resolution captive stepper linear actuators are tailored for demanding applications that need smaller move increments and finer positioning....

View product

20DBM-L High Power Stepper Linear Actuator

The 20DBM-L high resolution non captive stepper linear actuators are tailored for demanding applications that need smaller move increments and finer position...

View product

20DAM-K Permanent Magnet Stepper Digital Linear Actuator

The smallest of our linear actuator motor line, the 20DAM-K is a high-performance captive miniature linear actuator that provides...

View product

20DAM-L Permanent Magnet Stepper Digital Linear Actuator

The smallest of our linear acuator line, the 20DAM-L is a non-captive high performance linear actuator that provides a long stroke ...

View product

26DAM-K Permanent Magnet Stepper Digital Linear Actuator

The 26DAM-K is a captive linear actuator that provides up to 120 oz of linear force in a 26 mm frame size. Mclennan holds stock of ...

View product

26DAM-L Permanent Magnet Stepper Digital Linear Actuator

The 26DAM-L is a non-captive linear actuator that provides a long stroke length and up to 120 oz of linear force in a 26 mm frame si...

View product

26DBM-K Permanent Magnet Stepper Digital Linear Actuator

div class="field field-name-field-solution-info field-type-text-long field-label-hidden"> The 26DBM-K is a captive linear actuator tha...

View product

26DBM-L Permanent Magnet Stepper Digital Linear Actuator

The 26DBM-L is a non-captive linear actuator that provides a long stroke length and up to 128 oz of linear force in a 26 mm frame si...

View product

35DBM-K Permanent Magnet Stepper Digital Linear Actuator

The 35DBM-K is a captive linear actuator that provides up to 103.9 oz of linear force in a 35 mm frame size. The 7.5 degree step an...

View product

35DBM-L Permanent Magnet Stepper Digital Linear Actuator

The 35DBM-L is a non-captive linear actuator that provides a long stroke length and up to 103.9 oz of linear force in a 35 mm frame ...

View product

42DBL-K Permanent Magnet Stepper Digital Linear Actuator

The 42DBL-K is a captive linear actuator that provides up to 370 oz of linear force in a 42 mm frame size. The large rotor makes ...

View product

42DBL-L Permanent Magnet Stepper Digital Linear Actuator

The 42DBL-L is a non-captive linear actuator that provides a long stroke length and up to 370 oz of linear force in a 42 mm frame...

View product

57DBM-L Permanent Magnet Stepper Digital Linear Actuator

The largest of linear actuator line, the 57DBM-L is a non-captive linear actuator that provides a long stroke length and up to 448 ...

View product

Hybrid Stepper Motor Digital Linear Actuators

The full range of Hybrid Stepper Motor Linear Actuators offered by Applied Motion Products from the USA. These offer improved control and performance over th...

View product
